Quick Details

  • Brand Name: ODM/Hollyland
  • Model Number: HLHC0404A
  • Place of Origin: Guangdong, China (Mainland)
  • Housing: Metal
  • Package dimension: 223*180*50mm
  • Weight: 720g
  • Certificates: CE, FCC, RoHS
  • Distance: 50M
  • Support: EDID
  • Compitible: HDCP 1.2/dvi 1.0
  • Charter: Support 3g signal
  • Product name: Professional Audio Video 8x8 hdmi matrix for conference system
  • Input: 4 HDMI

Packaging & Delivery

Packaging Details Engineering level plastic package.
Professional Audio Video 8x8 hdmi matrix for conference system

Professional Audio Video 8x8 hdmi matrix for conference system

330 feet (100meters) over cat5e/6/7 HDBaseT

Features:

1,HDMI 1.3 SPEC and HDMI 1.4 3D supports.

2,HDMI HDCP 1.3 compatible

3,True 4 by 4 HDMI matrix, allow 4 outputs could selet the same or different HDMI source simultaneously.

4,The four outputs all iinclude one HDMI-A connecter and one RJ-45 connecter. They can output simultaneously.

5,The Cat5e/6 Outputs support power voer UTP,whose Cat5e/6 extender receiver can work without external DC adapter.

6,Support audio format PCM,Dolby-AC3,DTS 7.1.DSD.

7,HDP and CEC supports.

8,Both emitter and receiver 4*4 IR matrix embedded with local IR control.

9,Auto remembering last power-off matrix status and auto skip for unconnected inputs when power-on initialization.

10,EDID dynamic mixing managemen with maximum compatibility.

11,HDMI Cat5e/6 extenfer port support EDID call back.

12,Multi-mode control by LAN,RS232,Local IR remote,Cat5e/6 extender side IR receiver or panel button.

13,ESD protection level HBM ± 4 kv (Contact Discharge) for any input and output port.

14,Industrial metal case,easy to install.



Parameters:

interface4 HDMI input ports(female type A);4 HDMI outputs(femal type A);4 CAT5e/6 extender outputs(RJ45);4 IR out puts(3.5mm);4 IR inputs(3.5mm);RS 232 series ports;LAN port;12V DC in
Power consumption<30W when the function of power over UTP of 4 extender outputs are on.
Dimension(L*W*H):276*151*37)mm (No including 3mm height rubber pad)
Net weight2.5KG per unit
Input/Output Videl formatsHDMI V1.3,1080p/1080i/720p/576p/576i/480p/480i
HD interface standardHDMI 1.3 standard (HDMI 1.4 3D function),HDCP 1.3,Support CEC,EDID
Input video signal amplitude0.5-1.0 volts p-p
input DDC Signal5 volts p-p
HDMI Input/output audio formats PCM,Dolby-AC3,DTS 7.1,DSD,Maximum 8 channels
HDMI Input/output cable distance≥15m
Extender output resolution and distance

1080p 170ft--Cat5e/ 230ft--Cat6

7280p/108i 230ft-Cat5e/ 300ft -Cat6

IR frequencyWide frequency 20-60kHz
ESD levelHBM±4kv (contact discharge)
Temperature range0~40 °COperation),-20~60°C(Stock)
ComplianceFCC,CE
IndicatorsPower-Green,Extender output connected status-Green,Matrix Status-Yellow
